Mobile Surveillance Systems Affirm Unshakeable Smart Bus Commitment

NEXCOM’s Mobile Surveillance Systems fulfill mobile surveillance, fleet telematics, in-vehicle infotainment, and passenger Wi-Fi simultaneously, simplifying smart bus service delivery. Featuring system performance, flexible customization, industrial-grade reliability, and rich software utilities, MVS 5603-C6SMK and 2623-C6SMK are designed from the ground up to offer versatility and functionality required of smart bus applications. With NEXCOM’s Mobile Surveillance Systems onboard, smart buses can drive toward an intelligent future with enhanced transport safety, service efficiency, and passenger satisfaction.

To alleviate safety concerns over bus transport, the Mobile Surveillance Systems provide comprehensive surveillance coverage with six PoE ports with M12 connectors. While video streaming and recording is secured with screw-locking M12 connectors, footage can be stamped with GPS coordinates, time, speed, and other vehicle data to give more context as well as to facilitate video search. The MVS systems can help not only steer clear of door clamping accidents and rear-end collisions with blind spot monitoring but also produce video evidence to accelerate accident liability evaluation and dispute settlement. Considering the need of video retrieval, optional 3G/LTE/Wi-Fi connectivity is supported for remote access, and local storage units can be accessed externally.

Available with an Intel^® Core™ or Intel Atom^® processor, the Mobile Surveillance Systems have plenty of computing headroom to support fleet management at the same time. Equipped with a rich I/O set made of such as CAN bus, programmable GPIO, COM, USB, and a total of five expansion slots for mini-PCIe and M.2 modules, these MVS systems can flexibly be configured for onboard diagnosis over SAE J1939/1708 protocols, high-speed internet connections at up to 600 Mbps, and driver management and theft prevention leveraging iButton-based driver authentication and 24/7 tracking. For above scenarios to unfold, software utilities are built in to reduce engineering efforts and cut time to market of end applications.

Bus carriers can also take advantage of NEXCOM’s Mobile Surveillance Systems to improve passenger services. Route information display, audio stop announcement, news broadcasting, and advertising, among many other things, can be brought onboard by the MVS systems, and passenger Wi-Fi can be deployed with the integration of up to five Wi-Fi/3G/LTE modules which eliminate the need to install discrete Wi-Fi router units and lower the total cost of ownership for service delivery.

Main Features

• Flexible modular design for expansion with 4x mini-PCIe and 1x M.2
• Intel^® Core™ i7-6600U/i3-6100U or Intel Atom^® x7-E3950 processor
• 6x GbE 802.3 af/at PoE with M12 connectors
• Optional: 3G/LTE/WLAN with up to 5x SIM card holder
• Built-in GPS with optional dead reckoning support
• Built-in CAN 2.0B. with optional OBDII SAE J1939/J1708 support
• iButton for driver identification
• 2x external accessible SATA 3.0 SSD/HDD

Ordering Information

MVS 5603-7C6SMK (P/N: 10VS0560304X0)

Dual-core 6th generation Intel^® Core™ i7-6600U processor, 2.6GHz, 2GB of industrial-grade SO-DIMM DDR3L memory, 6x M12 GbE PoE, 2x GbE, VGA/HDMI output, 2x RS232, 1x RS-232/422/485, 4x USB3.0, 12VDC output, 1x CAN

MVS 5603-3C6SMK (P/N: 10VS0560303X0)

Dual-core 6th generation Intel^® Core™ i3-6100U processor, 2.3GHz, 2GB of industrial-grade SO-DIMM DDR3L memory, 6x M12 GbE PoE, 2x GbE, VGA/HDMI output, 2x RS232, 1x RS-232/422/485, 4x USB3.0, 12VDC output, 1x CAN

MVS 2623-C6SMK (P/N: 10VS0262301X0)

Intel Atom^® x7-E3950 processor, 2.0GHz, 2GB of industrial-grade SO-DIMM DDR3L memory, 6x M12 GbE PoE, 2x GbE, VGA/HDMI output, 2x RS232, 1x RS-232/422/485, 2x USB3.0, 1x USB2.0, 12VDC output, 1x CAN

VTK-CAN-04 (P/N: 10VK00CAN05X0)

2 x CAN2.0A/B, full-size mini-PCIe form factor, USB2.0 interface, DB9 cable

VTK-CAN-05 (P/N: 10VK00CAN06X0)

SAE J1708 module, full-size mini-PCIe form factor, USB2.0 interface, DB9 cable

VTK-CAN-06 (P/N: 10VK00CAN07X0)

1x CAN2.0A/B with SAE J1939, full-size mini-PCIe form factor, USB2.0 interface, DB9 cable
