V1100

EPIC Embedded Computing Board Powered by 11th Gen Intel® Core™ Processor
  • Main Feature
  • Onboard 11th Gen Intel® Core™ processor
  • Four 4K@60Hz display output thru 4 x HDMI 2.0
  • Dual LAN port, 3 x USB 3.0, 1 x USB 2.0 port for easy connection
  • 1 x M.2 3052 Key B for 5G/LTE module
  • 1 x M.2 2280 Key M for NVME/SATA storage
  • 1 x Full-size PCI express mini card slot
Add to Inquiry
Datasheet(PDF)
CPU Support Onboard 11th Gen Intel® Core™ i3-1115G4E processor, Dual Core, 2.2 GHz, 6M cache Onboard 11th Gen Intel® Core™ i5-1145G7E processor, Quad Core, 1.5 GHz, 8M cache Onboard 11th Gen Intel® Core™ i7-1185G7E processor, Quad Core, 1.8 GHz, 12M cache
Chipset SoC
Main Memory 2 x 260-pin SO-DIMM socket support DDR4 non-ECC memory, dual channel, up to 32GB
Graphics & Display Intel® UHD graphics i3 processors Intel® Iris® Xᵉ graphics on i5 and i7 processor 4 x HDMI 2.0, support 4096 x 2160@60Hz
LAN 1 x Intel® i219-LM GbE PHY support PXE boot from LAN, wake on LAN function 1 x Intel® i225-V 2.5G LAN controller PXE boot from LAN, wake on LAN function
Storage 1 x M.2 2280 Key M (PCIe 4.0 x4, SATA 3.0), support storage modules 1 x SATA 3.0 & SATA power connector for optional 2.5” SSD
I/O Function - Edge 1 x 12V DC Jack 4-pin 4 x HDMI 2.0 1 x GbE LAN, 1 x 2.5GbE LAN 3 x USB 3.2, 1 x USB 2.0
I/O Interface-Internal 4 x USB 2.0 1 x 9-pin Line-out/Mic-in 1 x 8-pin GPIO (4-in/4-out) 1 x RS232/422/485, 1 x RS232
Expansion 1 x M.2 3052 Key B for 5G/LTE module 1 x M.2 2280 Key M for NVME/SATA storage 1 x Full-size PCI express mini card slot
Power Requirement 12V/8A DC input thru 4-pin DC Jack (colay with internal connector, ATX 4-pin (ATX 4 pin: optional))
Environment Operating temperature: 0°C to 60°C Storage temperature: -40°C to 80°C Humidity: 10 to 90% (non-condensing)
Certification CE Approval FCC Class A
Dimensions 165mm (W) x 123mm (D)
Operating System Win10/Linux
